• DanCrossNYC: The TSC ticks at a fixed rate now days, regardless of voltage scaling on the CPU.
• jbk: just x86 doesn't provide a consistent want to determine what the rate is
• jbk: (I guess some chips will tell you via CPUID, but I've yet to actually encounter such chips)
• jbk: some hypervisors will tell you via an MSR
• zorg24: Looks the Linux kernel docs have some documentation on the x86 TSC and PIT https://www.kernel.org/doc/html/next/virt/kvm/x86/timekeeping.html
• DanCrossNYC: CPUID or an MSR, but yeah, most systems sample over a fixed interval (determined by another time source) to figure it out.
• jbk: no, versus some other present component that allows you to measure the frequency
• DanCrossNYC: No, the PIT or HPET or something.
• jbk: https://src.illumos.org/source/xref/illumos-gate/usr/src/uts/i86pc/os/tscc_pit.c?r=236cb9a8
• jbk: is how it uses the PIT
• jbk: (the HPET code needs to improve it's accuracy, so it's only used when the PIT isn't there at the moment)
• jbk: some Intel NUCs have no PIT
• jbk: so HPET is the only option
• bcantrill: https://github.com/illumos/illumos-gate/commit/717646f7112314de3f464bc0b75f034f009c861e
• DanCrossNYC: Two big ones: system maintenance without disturbing guest workloads, and also load balancing across a rack.
• "Sevan: ah, thanks.
• https://github.com/illumos/illumos-gate/blob/717646f7112314de3f464bc0b75f034f009c861e/usr/src/test/bhyve-tests/tests/common/common.c#L166"
• bcantrill: https://github.com/oxidecomputer/tsc-simulator/tree/master
• DanCrossNYC: The guest may well be running NTP itself.
• iangrunert: I assume you could also check that NTP is alive / has synced recently before doing a migration right?
• aka_pugs: Do people use IEEE 1588/PTP in datacenters? Maybe finance wackos?
• zorg24: also it might be tricky to check if NTP synced recently if it is happening in usermode
• iangrunert: Might've missed this - is it just the hypervisor that has to run NTP recently or the VM as well?
• saone: I believe it was just the hypervisor
• DanCrossNYC: The host.
• DanCrossNYC: A guest may or may not; that's up to the guest.
• jbk: but IIUC, if the guest IS running NTP, then the host definitely needs it to avoid any time warps
• DanCrossNYC: Yup.
• DanCrossNYC: Fortunately, there's a bit of an out for the blackout window during migration: SMM mode can effectively pause a machine for an indefinite period of time.
• DanCrossNYC: We don't USE SMM anywhere, but robust systems software kinda needs to handle the case where the machine goes out to lunch for a minute.
• zorg24: 🙌 hooray for hardware with no SMM use
• DanCrossNYC: We have done everything we can to turn it off.
• ahl: https://github.com/dtolnay/case-studies/blob/master/autoref-specialization/README.md
• ahl: https://github.com/oxidecomputer/propolis
• earltea: it worked so well I almost thought the VM didn't migrate 😅
• saone: It's easy to forget that there's a world outside the cloud, but edge deployments that have physical peripherals hooked up need to maintain those connections to peripherals; migrating those peripherals to cloud environments and managing that integration has been a big challenge for my group.
• iangrunert: https://signalsandthreads.com/clock-synchronization/ Good listen about clock synchronization and PTP in the ""finance weirdos"" world. MiFID 2 time sync requirements require timestamping key trading event records to within 100 microseconds of UTC.
• jhendricks: a bit belated, but the propolis side of these changes: https://github.com/oxidecomputer/propolis/commit/7ed480843d3b5cfd9fd07dce41772f8eac4e9171
• saethlin: The calvalry??
• saethlin: Are we just going to let that slide
• saethlin: Is this a pronunciation situation again
• zorg24: not the first time I've heard it pronounced that way 🤷
• saethlin: Well maybe it's me learning this time
• DanCrossNYC: Calvary
• DanCrossNYC: That's the religious thing.
• ahl: https://github.com/illumos/illumos-gate/blob/0c5967db436935325af441af2b27d337f4e64af5/usr/src/uts/common/os/cyclic.c#L44
• zooooooooo: thought this was rust typescript at first 😳
• DanCrossNYC: Dunno... I missed it. 🙂
• ahl:

 *  Starting in about 1994, chip architectures began specifying high resolution
 *  timestamp registers.  As of this writing (1999), all major chip families
 *  (UltraSPARC, PentiumPro, MIPS, PowerPC, Alpha) have high resolution
 *  timestamp registers, and two (UltraSPARC and MIPS) have added the capacity
 *  to interrupt based on timestamp values.  These timestamp-compare registers
 *  present a time-based interrupt source which can be reprogrammed arbitrarily
 *  often without introducing error.  Given the low cost of implementing such a
 *  timestamp-compare register (and the tangible benefit of eliminating
 *  discrete timer parts), it is reasonable to expect that future chip
 *  architectures will adopt this feature.

• aka_pugs: Bryan's TSC is overflowing.
• DanCrossNYC: That's Tom.
• DanCrossNYC: Riding in with the cavalry.
• aka_pugs: Good session.
• ahl: Thanks Jordan and everyone who joined us live; we'll make this chat read-only in just a few minutes
• bcantrill: Yes, thank you Jordan
